Cordless Hammer Drill Driver

TP-CD 18/120 Li-i BL; EX; NA

Article no.: 4514380 UPC: 772995020478
  • Part of the Power X-Change family, 1 x 18 V battery required
  • Brushless motor - more power and longer runtimes
  • Hammer drilling function for stone and masonry
  • High-quality 1/2” keyless metal drill chuck
  • Electronic speed control to suit material/application
  • 2-speed gearbox for powerful drilling and screwing
  • Ergonomic design with softgrip for comfortable work
  • Practical belt clip for efficient and safe operation
  • Integrated LED light to illuminate the working area
  • Comes with additional handle
  • It comes without battery or charger
  • The battery/charger are available separately
See more information
Show less information
einhell-professional-cordless-impact-drill-4514380-productimage-001
Article description

The Einhell 1/2" Professional cordless hammer drill/driver 4514380 is the perfect addition to any ambitious DIY expert's workshop. As part of the Power X-Change family, it is compatible with every charger and battery in the innovative system. The tool is powered by an Einhell brushless motor. This brushless motor offers more power and a longer runtime than conventional carbon brush motors. Once you register online, the brushless motor has a 10-year warranty. With its hammer drilling function, it supports professional craftsman when working on resistant materials such as stone or concrete. In addition, the hammer drill/driver has a 2-speed gearbox that allows fast screwing, drilling and powerful impact drilling. The torque-slip clutch prevents screws from being overtightened. The hard torque of 1062 in/lbs is adjustable over 21 torque levels. The hammer drill/driver also offers a drilling stage and an impact drilling stage. The variable speed electronics support application- and material-appropriate work. The single-sleeve 1/2" metal keyless chuck with locking function allows a quick and easy change of the tool. Safe and wrist-friendly operation is ensured by the additional handle with softgrip. The LED light provides a good view of the work area even in poor visibility. For safe storage, the hammer drill/driver can be easily attached to the belt with the belt clip. Battery and charger are not included . These are available separately.

See more information
Show less information

Technical details

Motor typeBrush motor
Motor voltage18V
Number of gears2
Idle speed (gear 1)0 - 500 RPM
Idle speed (gear 2)0 - 2,100 RPM
Hammer speed (gear 1)0 - 6,550 BPM
Hammer speed (gear 2)0 - 27,300 BPM
Max. torque1062 in/lbs (120 Nm)
Number of torque steps21+1+1 settings
Drill chuck1/2"|single sleeve
Product weight4 lbs
Gross weight5.55 lbs
Packaging dimensions (LxWxH)10.82" x 3.97" x 14.68"
